DKC-900 Upgrade Kit
Hardware Upgrade for Mark IV and E3 generation Disklavier Supported file formats: Standard MIDI, MP3, WAV, Analog-MIDI 500 built-in songs Available songs: 9,000 Streaming radio service with 30+ channels Streaming video service (free with radio subscription) Compatible storage media: USB Flash Memory (up to 128GB) MIDI connectivity: 5-pin MIDI IN/OUT, USB TO HOST Audio connectivity: Analog audio IN x2, analog audio OUT x 4, digital coax OUT (2CH) Data connectivity: LAN, USB TO DEVICE x 3 (uprights x 2) Control integration: iOS/Android app, Mac/PC browser, MusicCast app, custom API Compatible models: Mark IV (all models) E3 (all models) Supplied accessories: Owner’s manual, Built-in song list, Audio cable, AC Adaptor, USB wireless LAN adaptor, Bracket Optional accessories: Bracket for CF Series Grand Piano (DKCB-900CF) Specifications as of 01/2020. Specifications subject to change without notice.
DKC-900 | ||
---|---|---|
Size/Weight | ||
Dimensions | Width | Switch Box: 220 mm/Control Center Unit: 224 mm |
Height | Switch Box: 30 mm/Control Center Unit: 76 mm | |
Depth | Switch Box: 70 mm/Control Center Unit: 130 mm | |
Voices | ||
Tone Generation | Piano Sound | CFX Binaural Sampling, CFX Stereo Sampling |
Polyphony | Number of Polyphony (Max.) | 256 |
Number of Voices (Playing) | 16 (Piano, Electric Piano 1-3, Harpsichord 1 & 2, Vibraphone, Celesta, Pipe Organ 1-4, Jazz Organ, Strings, Choir, Synth Pad) | |
Preset | Featured Voices | Normal Voices: 480/Drum Voices: 12 kits total |
Compatibility | XG | Yes |
GM | Yes | |
Songs | ||
Number of Built-in Songs | 500 | |
Compatible Data Format | SMF (Standard MIDI File, Format 0 & 1), MP3, WAV | |
Compatible Song Format | PianoSoft, PianoSoft Plus, PianoSoft Audio, SmartKey | |
Functions | ||
Overall Controls | Tuning | 414.8 Hz to 466.8 Hz (tunable in 0.2 Hz increments) |
Storage and Connectivity | ||
Connectivity | Headphones | Mini Stereo Jack x1 |
MIDI | IN/OUT | |
OUTPUT | Yes | |
DIGITAL OUT | Yes | |
USB TO DEVICE | x3 | |
USB TO HOST | Yes | |
LAN | Yes | |
OMNI (SYNC) | IN/OUT | |
Compatible Storage Media | USB Flash Memory (Optional) | Yes |
Power Supply | ||
Power Requirements | AC 100 V to 240 V, 50/60 Hz | |
Accessories | ||
Included Accessories | Others | Owner's manual, Built-in song list, Audio cable, AC adaptor, USB wireless LAN adaptor, Bracket |
